8" L7 4Ω Subwoofer
Price: $499.95 - Not available online
Style. Substance. The L7™ brings award-winning innovation to you with the original square subwoofer.

THE 8" L7 4Ω

The KICKER L7™ 8- inch Subwoofer features a cone shape designed to produce more output. The ultra-rigid, injection-molded square cone was a KICKER first, while the patented ribbed corners allow extreme flexibility.

Oversized ceramic magnets deliver precise voice-coil control, while finned, aluminum heat sinks maximize heat dissipation for best results under stress.

This combination of power, engineering and unrivaled performance is why the L7 remains the best subwoofer in the car audio world.

L7 8" Specifications
Rated Impedance [Ω]
4
Fs [Hz
47.2
Sensitivity [1W, 1m]
82.4
Qts
0.735
Qms
8.828
Qes
0.802
Re [Ω]
6.6
Vas [ft³, L]
.322, 9.127
Continuous Power Handling [Watts RMS]
500
Outer Frame Dimension [in, cm]
8-13/16, 22.4
Mounting Depth [in, cm]
5-7/16, 13.8
Mounting Cutout [in, cm]
7-1/4, 18.4
Frequency Response [Hz
28 - 100
Sealed Enclosure Specs
Minimum Sealed Volume ft3 (L)
.4 (11.33)
Minimum Sealed Power Handling
500W RMS
Maximum Sealed Volume ft3 (L)
75 (21.24)
Maximum Sealed Power Handling
500W RMS
Panel Dimensions for Minimum Sealed Enclosures using 3/4” (1.9cm) thick MDF
Box Volume [ft³, L]
.4 (11.33)
Panel A [in, cm]
11x11, 27.9x27.9
Panel B [in, cm]
11x7.75, 27.9x19.69
Panel C [in, cm]
9.5x7.75, 24.13x19.69
Vented Compact
Box Volume, ft³ (L) + port displacement
.66 (18.69)
Port Opening Size, in x in (cm x cm)
1.5x9.5 (3.8x24)
Port Length, in (cm)
19.25 (49)
Power Handling, RMS
500
Vented SQ
Box Volume, ft³ (L) + port displacement
1 (28.32)
Port Opening Size, in x in (cm x cm)
2x9.5 (5.1x24)
Port Length, in (cm)
21.25 (54)
Power Handling, RMS
500
