15" Solo-Baric L7 4 Ohm
Price:
The KICKER® Solo-Baric® L7S™ boasts massive power handling and more cone area than any circular sub. You move more air, so you get more bass.

Square Matters

The heavy-duty motor structure includes a large-diameter spider for less flex, longer life and superior accuracy. High-temp voice coil wire winding completes a powerful Comp motor that makes the most of every watt you give it.

Features:

  • Dual Four-Ohm Voice Coils
  • Injection-Molded Polypropylene Cone
  • Patented Corner Ribs Minimize Distortion
  • SoloKon™ 360-Degree Back Bracing
  • Ribbed Santoprene Surround With Blue Surround Stitching
  • UniPlateā„¢ Back Plate And Pole Piece, Plus Perimeter Venting For Excellent Thermal Management
  • Thick Tinsel Leads
  • Large Ceramic Magnet
  • Cast Aluminum Basket
  • Satin-Nickel Plated, Spring-Loaded Speaker Terminals

Want setup help? Go to KICKERU for a free woofer & amplifier configuration app!

*The Solo-Baric L7S 15-Inch Subwoofer works best with a sealed or ported enclosure and 1,000 watts of recommended power. See below for more details.

Specifications
Size (IN.,CM)
15, 38.1
Impedance (OHMS)
4 DVC
Max Rec Amplifier Power (WATTS PEAK/RMS)*
2000/1000
Sensitivity (dB 1w/1m)
89.4
Frequency Response (Hz)
18-100
Mounting Depth (IN.,CM)
8-11/16, 22.1
Mounting Cutout, Square (IN.,CM)
13-3/4, 34.9
Min Rec Sealed Box Volume (CU. FT., Liters)
2.0, 56.64
Max Rec Sealed Box Volume (CU. FT., Liters)
6.0, 169.9
Min Rec Vented Box Volume (CU. Ft., Liters)**
3.0, 85.0
Max Rec Vented Box Volume (CU. Ft., Liters)**
6.0, 169.9
What's in the box?
one 15-inch subwoofer, one owner's manual, two stickers

*Assumes typical music program with minimal amplifier clipping; varies with enclosure size. See your KICKER dealer for details.

**Port Volume Excluded.

Due to continual developement, product, and specifications are subject to change without notice. Stillwater Designs and it's agents are not responsible for typographical errors.
