8" Solo-Baric L7S 2 Ohm
Price:
The KICKER® Solo-Baric® L7S™ features next-level materials and heat management technology for clear, pounding bass that lasts.

Square Matters

The Solo-Baric L7S's square sub design delivers dependable bass - even when pushed to the limit. Dual voice coils with high-temp copper windings easily handle intense heat and power levels for clean, clear bass anytime.

Features:

  • Dual Two-Ohm Voice Coils
  • Injection-Molded Polypropylene Cone
  • Patented Corner Ribs Minimize Distortion
  • SoloKon™ 360-Degree Back Bracing
  • Ribbed Santoprene Surround With Blue Surround Stitching
  • UniPlate™ Back Plate And Pole Piece, Plus Perimeter Venting For Excellent Thermal Management
  • Thick Tinsel Leads
  • Large Ceramic Magnet
  • Cast Aluminum Basket
  • Satin-Nickel Plated, Spring-Loaded Speaker Terminals

Want setup help? Go to KICKERU for a free woofer & amplifier configuration app!

*The Solo-Baric L7S 8-Inch Subwoofer works best with a sealed or ported enclosure and 450 watts of recommended power. See below for more details.

Specifications
Size (IN.,CM)
8, 20.32
Impedance (OHMS)
2 DVC
Max Rec Amplifier Power (WATTS PEAK/RMS)*
900/450
Sensitivity (dB 1w/1m)
83.6
Frequency Response (Hz)
28-100
Mounting Depth (IN.,CM)
4-3/4, 12.1
Mounting Cutout, Square (IN.,CM)
7-1/4, 18.4
Min Rec Sealed Box Volume (CU. FT., Liters)
.5, 14.16
Max Rec Sealed Box Volume (CU. FT., Liters)
.75, 21.24
Min Rec Vented Box Volume (CU. Ft., Liters)**
.66, 18.6
Max Rec Vented Box Volume (CU. Ft., Liters)**
1.0, 28.3
What's in the box?
one 8-inch subwoofer, one owner's manual, two stickers

*Assumes typical music program with minimal amplifier clipping; varies with enclosure size. See your KICKER dealer for details.

**Port Volume Excluded.

Due to continual developement, product, and specifications are subject to change without notice. Stillwater Designs and it's agents are not responsible for typographical errors.
