DS Series 5.25" Coax
Price:
The 2014 DS Coaxials are a drop-in coaxial upgrade with the flexibility to fit nearly any vehicles doors for a vast improvement over factory sound.

DS-Series 5.25" Coaxial

The 2014 DS 5-1/4-Inch Speakers are a great way to upgrade the sound in your car.

A stamped steel framework supports a ribbed, UV-treated foam surround and rigid polypropylene cone with EVC™ (Extended Voice Coil) technology, for the best sonic quality. Add a DX amplifier to increase the level and quality of the volume in your ride.

These DS speakers work best with 90 watts of recommended power. See below for more details.

DSC54 Specifications
Speaker Design
2 - way
Woofer [in, mm]
5-1/4, 130
Tweeter [in, mm]
1/2, 13
Rated Impedance [Ω]
4
Peak Power Handling [Watts]
200
Continuous Power Handling [Watts RMS]
50
Sensitivity [1W, 1m]
90
Frequency Response [Hz]
45-20k
Mounting Hole Diameter [in, mm]
4-1/2, 115
Top Mount Depth [in, mm]
1/4, 7
Bottom Mount Depth [in, mm]
1-3/4, 45
Tweeter Protrusion [in, mm]
0
Grilles
Yes
Tweeter Magnet Material
Neodymium
Tweeter Dome Materia
PEI (polyether imide)
Tweeter Design
Balanced dome
Woofer Cone Material
Polypropylene
Woofer Surround Material
Polyester foam

*Power handling assumes typical music program with minimal clipping. See your KICKER dealer for complete details. Based on measurements of 4Ω models.
