KS Series ¾" Tweeter
Price:
KICKER’s® elite KS tweeter upgrade is an excellent addition to any sound system that needs more accuracy and realism.

KS Series ¾" Tweeter

The KS ¾-Inch Tweeter is a silk dome, complete with a trio of mounting options and an in-line 12dB crossover.

Features:

  • Silk Dome Tweeters For A Smooth Sound
  • Three Tweeter Mounting Options (Hardware Included)
  • Extended Frequency Response
  • Lightweight Neodymium Magnets
  • In-Line12dB Crossover Included
  • Poly-Switch Protection
  • Grilles Included

The tweeter works best with 65 watts of recommended power. See below for more details.

Mounting Options

When it comes to mounting your tweeters, the KS Series ¾" Tweeter gives you plenty to choose from!

Specifications
Tweeter [in,mm]
¾, 20
Tweeter Dome Material
Silk
Rated Impedance [Ω]
4
Peak Power Handling [Watts]
125
Continuous Power Handling [Watts RMS]
65
Sensitivity [1W, 1m]
92
Frequency Response [Hz]
4500-21k
Flush Mount Tweeter Depth [in, mm]
½, 12
Flush Mount Tweeter Hole Diameter [in, mm]
1-916 , 40
High Pass [dB], at Frequency [Hz]
12, 4500
Support

Manuals


2017 KS Tweeters | Multilingual | Download

Do you have a different model? Click Here
