DS Series 3.5" Coax
Price:
The 2014 DS Coaxials are a drop-in coaxial upgrade with the flexibility to fit nearly any vehicles doors for a vast improvement over factory sound.

DS-Series 3.5" Coaxial

The DS 2014 3-1/2-Speakers are a great way to upgrade the sound in your car.

Using zero protrusion PEI tweeters ensures you get every bit of clarity you need, without interfering with factory grilles. A st amped steel framework supports a ribbed, UV-treated foam surround and rigid polypropylene cone for the best sonic quality. Add a DX amplifier to increase the level and quality of the volume in your ride.

These DS speakers work best with 20 watts of recommended power. See below for more details.

DSC354 Specifications
Speaker Design
2 - way
Woofer [in, mm]
3-1/2, 89
Tweeter [in, mm]
1/2, 13
Rated Impedance [Ω]
4
Peak Power Handling [Watts]
80
Continuous Power Handling [Watts RMS]
20
Sensitivity [1W, 1m]
88
Frequency Response [Hz]
80-20k
Mounting Hole Diameter [in, mm]
3, 78
Top Mount Depth [in, mm]
1/4, 6
Bottom Mount Depth [in, mm]
1-11/16, 42
Tweeter Protrusion [in, mm]
1/8, 3
Grilles
No
Tweeter Magnet Material
Neodymium
Tweeter Dome Materia
PEI (polyether imide)
Tweeter Design
Balanced dome
Woofer Cone Material
Polypropylene
Woofer Surround Material
Polyester foam

*Power handling assumes typical music program with minimal clipping. See your KICKER dealer for complete details. Based on measurements of 4Ω models.
