CX900.1 Mono Amplifier

The CXA900.1 Mono Amplifier is built for affordable power and performance, thanks to optimized circuit layout and high-grade internal components. Additional CXA-Series Amps will be available by January 2027 featuring higher power and a fresh look.

Model: 53CXA9001

Angled top view of KICKER CXA800.1 car amplifier showing compact chassis and terminal connections.

About that Power

CX-Series Mono Amps are one-ohm stable, giving you even more power and wiring options for your system! This Class-D CXA900.1 supplies even more bass power than its predecessor, and it features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump. A precise 24dB crossover and 24dB subsonic filter is included, letting you quickly tune your system to perfectionwhile providing proper protection. Use the full-range outputs to expand your system with other bass amps or a full-range amp to complete your sound. From your dash, a simple turn of the optional CXARC Remote Bass Controller (sold separately) increases your output to fit your choice of music.

CXA-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

This CXA.1 Amplifier delivers as much as 900 watts into one bass channel. See below for more details.

Side view of vertically mounted KICKER CXA800.1 car amplifier showing control panel and RCA inputs.

Class-D Design for lower current draw and operating temperatures, and active thermal rollback for all-day play
FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
24dB/octave LP Crossover for cleaner bass, reduced distortion, and improved subwoofer power handling
24dB Subsonic Filter for protection from potentially damaging frequencies
Gain-Match LED Indicator for dialing in the perfect gain setting
KickEQ™ Boost variable up to 6dB for louder deep bass
Accepts up to 40-volt input signal
Three-second turn-on / off delay to eliminate unwanted interference
Small footprint for easier installation
Compatible with CXARC Remote Bass Control

If you have two mono amps or powered subwoofers, check out the DBRC Remote for controlling both from the same knob.

Specifications

CXA900.1 White Paper

53CXA9001-wp.pdf

RMS Power [Watts Channel] @ 14.4V

1Ω mono: 900W
2Ω mono: 600W
4Ω mono: 350W

Dynamic Power [Watts]

1000

Frequency Response [Hz]

15-200, +0/–6dB

Signal-to-Noise Ratio
(a-weighted, re: rated power)

>95dB

Signal-to-Noise Ratio
(ref: 1W output)

>75dB

Dimensions [in, cm]

Height: 2-7/32 (5.6cm) Width: 6-27/32 (17.4cm)
Length: 7-1/16 (18cm)

Input Sensitivity

High level 1V–40V
Low level 125mV–5V

Electronic Crossover

variable Lo-Pass 50–200Hz, 24dB/octave LR

Subsonic Filter

15Hz @ 24dB/octave

KickEQ+™ Bass Boost

variable 0-6dB @ 40Hz

CXARC Remote Bass Capable [sold sep.]

yes

Warranty

When purchased from an Authorized KICKER Dealer or kicker.com, KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of TWO (2) YEARS from date of original purchase.
Complete warranty information here.

*RMS Power test @ 14.4V @ < 1% THD+N, Audio Precision® APx500 analyzer, see www.kicker.com/amp-power-testing for details.

**Dynamic Power test @ 14.4V @ < 10% THD+N, Audio Precision APx500 analyzer, see www.kicker.com/amp-power-testing for details.

Audio Precision is a registered trademark of Audio Precision in the United States and other countries.
