KXMA1200.2 Amplifier
The KXM 1200-watt stereo amplifier is built for massive full range power.
KickEQ+™ delivers as much as an 18dB of extra bump with a simple turn of the knob, while a powerful 24dB crossover lets you quickly tune your system to perfection.
A full range RCA output allows you to easily add another amplifier without running new signal cable to the radio.
Features:
- Class D Power Plant
- Gain Control With "Optimal Input" Indicator
- FIT2™ (Fail-Safe Integration Technology) Circuitry
- Variable 24dB Crossover
- DSP-Controlled Preamp
- KickEQ+™ 18dB Variable Bass Boost
- ABYC/NMMA Compliant Power Terminals
- Conformal-Coated Circuit Boards
- Easy Access to Settings behind Gasket-Sealed Cover Panel
- Black Anodized Aluminum Chassis
- Top-Mounted Teal LED Light Pipe
- Stainless Steel Mounting Hardware Included
Want setup help? Go to KICKER U for a free woofer & amplifier configuration app!
This KXM amplifier delivers up to 600 watts per channel. See below for more details.
| RMS Power [Watts] |
| @ 14.4V, 4Ω stereo, ≤ 1% THD+N : 300 x 2 @ 14.4V, 2Ω stereo, ≤ 1% THD+N : 600 x 2 |
| Length [in, cm] |
| 11-3∕16 , 28.4 |
| Height [in, cm] |
| 2-⅛, 5.5 |
| Width [in, cm] |
| 8-5⁄16 , 21 |
| Frequency Response ± 1dB |
| 10Hz–20kHz |
| Signal-to-Noise Ratio |
| 95dB |
| Input Sensitivity |
| 250mV–10V |
| Selectable Electronic Crossover |
| Off Variable HP, 10-500Hz Variable LP, 40-500Hz; 400Hz–5,000Hz with 10X Switch (BP capable) Slope: 24dB/octave |
| KickEQ™ Bass Boost |
| 0-18dB @ 40Hz |
| CEA Power |
| 300 x 2 @ 4 ohms, 14.4VDC, 1% THD, CEA-2006B (Watts) |
| CEA Signal-to-Noise Ratio |
| -75dB CEA-2006B (ref: 1W, A-weighted) |
Manuals
2017 KXM Stereo Amplifier | Multilingual | Download
